Metal Powder screening machine
Powder screening machine is used for powder material screening. The mesh can be 500 mesh.
Description
Product brief
Powder screening machine is used for powder material screening. The mesh can be 500 mesh.
For fine powder screening, the ultrasonic screening machine are often recommended. It has ultrasonic deblinding system to solve clogging. Full enclose design avoid the dust spilling to pollute the environment.
Features:
It is suitable for powder separation or impurity removal
3-5 min quick change the screen mesh
Full enclosure can combine free dust conveying with free dust feeder and conveyor
No clogging, high screening efficiency
Technical parameter
| Model | B-40 |
| Diameter (INCH) | 40 |
| Sieving area (M2) | 0.6359 |
| Motor Powder(kw) | 1.1 |
| package size(mm) | 1160*1160*810 |
| weight( kg) | 245 |
| Screen mesh | B-40 |
| Layer | 40 |
| Customized service | Charging port: can be soft pipe or hopper Cover: Polishing or sandblast Material: stainless steel, carbon steel, material contact part stainless Motor brand: Oli motor well known brand or Chinese ordinary motor Discharging port: Straight Flo or valve control |
Application
Ultrasonic vibrating screen is used in silicon carbide, alloy powder, molybdenum powder, stainless steel powder, tungsten powder, nickel powder, cobalt powder, powder coating, quartz powder, bumethone powder, malt powder, ribavirin, coffee powder, electromagnetic powder, negative electrode Materials, laser powder and other fields.
Package
Outer packing is plywood case, conform to the international standards.
Inner packing is Moisture-proof and water-proof membrane.
All of package are wrapped by 0.5mm steel belt to further strengthen.
