Frac sand vibrating screen
Frac sand vibrating screen is granular powder screening machinery
Description
Product brief
Frac sand vibrating screen is granular powder screening machinery. Gyratory screen adopts to Rotex technology, so it also is called Rotex screen,
which can change material distribution during different screening stage. Automatic cleaning- Bouncing balls keep screen surface clean to improve
the efficiency and capacity.
Features:
All parts are easily accessible and removable for ease of disassembly and cleaning.
Max layers can be up to 8 layers
Low energy consumption, higher screening efficiency.
Long service life because no vibration
Quick replacing the screen mesh
Technical parameter
| Model | BFY-1230 | BFY-1236 | BFY-1536 | BFY-1836 | BFY-2040 |
| Screen Size(mm) | 1200×3000 | 1200×3600 | 1500×3600 | 1800×3600 | 2000×4000 |
| Material Granularity | 6mm – 0.075mm | ||||
| Angle | 5°-8° | 5°-8° | 5°-8° | 5°-8° | 5°-8° |
| Layer | 1-5 | 1-5 | 1-5 | 1-5 | 1-5 |
| Power | 4kw | 4kw | 5.5kw | 7.5kw | 7.5kw |
Application
It is extensively used in chemical and new materials, metallurgy, metal powder, mineral powder, food, salt, sugar, abrasives, feed
and other industries. It is suitable for large yields and batch screening demand.
FAQ
- What material you will siftand material characteristics, such as solid, liquid, particle, or powder?
- What sieving purpose you hope to realize, grading, de-rust, or filtering?
- How many is the output you demanded?
- How many is your material size?
- What is your power voltage?
